Bambu Lab H2D – Rethink Personal Manufacturing

All-In-One Personal Manufacturing Hub – The Bambu Lab H2D Integrates 3D printing, laser engraving/cutting, and digital cutting/plotting in a unified platform.

Product Features

• Dual-nozzle Multi-material 3D Printing
• Optional 10W/40W Laser and Cutting Module
• 350*320*325 mm³ Print Volume
• 5μm Resolution Optical Motion Calibration
• Closed-loop Servo Extruder
• 350°C Nozzle & 65°C Active Chamber Heating

Revolutionising Accuracy – One order of magnitude higher motion accuracy.

Dual-Nozzle, Double Flexibility – Fast and efficient multi-material printing!

AI-Powered Simplicity – 4 computer vision cameras*, 36 sensors, 2 servo motors united by a sophisticated algorithm for your simplicity.*

Next-Gen Filament Management – Drying, feeding and storage in a single package.

Endless Possibilities of Personal Manufacturing

Personal Manufacturing Hub
The Bambu Lab H2D is not only a 3D printer, it adds laser engraving and cutting, digital cutting and plotting to your studio, unlocking new creative possibilities.

Laser
10W and 40W 455nm Laser for engraving & cutting

Digital Cutting
Precise cutting on a variety of materials

Pen Drawing
Drawing and writing

A Hard Core Laser Machine

High Power 455nm Laser
Cut 5mm plywood with the 10W laser, and 15mm plywood with the 40W laser.

Air Assist
Improve surface quality by directing high-speed air to cool the laser path, ensuring cleaner and more precise results.

Contact-less 3D Mesh*
Advanced optical height measurement creates a detailed 3D mesh without physical contact, enabling precise laser work on curved surfaces.

Rotary Attachment
Expand your capabilities with the rotary attachment, allowing laser engraving on cylinders, spheres, and rings.*

Laser Safety Windows
Operate and monitor laser projects safely without the need for goggles.

Air Purifier
An optional air purifier ensures clean air, even during indoor laser operations.*

Live Spatial Alignment – What-You-See-Is-What-You-Get
The Bambu Lab H2D BirdsEye camera, combined with computer vision algorithms, delivers top-view alignment accuracy up to 0.3mm. This advanced spatial alignment allows users to place the tool path at the right position on the material – truly “what-you-see-is-what-you-get.”*

Print-Then-Cut – Make colorful projects with ease
Instantly transform graphic prints into precise cuts. Design and print with Bambu Suite and your graphic printer, then use the H2D to cut it out. Its AI camera automatically aligns the cutting path to the graphic, ensuring perfect registration with minimal effort.

Auto Arrangement – Maximize material efficiency, minimize waste
Leveraging real-time images from the BirdsEye camera, Bambu Suite can automatically arrange your project according to the shape of your material, i.e leftover plywood from the previous project. This feature helps you to get the most out of every material.

Bye-bye to manual laser focusing and thickness setting – Full-Auto Calibration
A single tap initiates automated laser focus verification and material measurement, eliminating manual adjustments.

Material CodeSync – The Bambu Lab H2D automatically scans the QR code on your material to load the perfect preset.* Revolutionizing Accuracy
With a motion system that is 10 times more accurate, H2D significantly reduces the hassle of tweaking designs and settings to accommodate standard components or fitting printed parts together.

Our Secret Weapon: Vision Encoder – 50µm ultra-fine motion accuracy*
An ultra-accurate vision encoder plate, combined with 5µm resolution optical measurements to track and correct toolhead motion, enables the H2D to achieve consistent and reliable distance-independent 50μm motion accuracy across the entire workspace, one order of magnitude better than its predecessor. (*Vision Encoder sold separately)

Auto Hole/Contour Compensation – Perfect fit, first time, every time – no adjustments needed*
Thanks to H2D’s enhanced motion accuracy and Bambu Studio’s specialized calibration for selected Bambu Lab filaments, you can achieve perfect fits with standard parts like steel shafts every time—no more tedious gap adjustments needed.

Dual-Nozzle, <25μm Offset – Two nozzles that print like one
Our state-of-the-art nozzle sensing technology provides fast and reliable calibration, aligning both nozzles before each print. The non-contact measurements are robust and unaffected by nozzle contamination.

Nozzle Pressure Sensing and Active Flow Rate Compensation – Smooth surfaces, sharp edges
H2D uses both the sensing capability of its servo motor on the extruder and the high-resolution eddy current sensors on the nozzle to precisely control extrusion by measuring nozzle pressure and calibrating PA parameters for each filament, improving surface smoothness and edge sharpness.

Active Vibration Compensation – Silky smooth at lightning speed
To minimize banding artifacts during high-speed printing, H2D employs automatic vibration compensation. Using toolhead sensors, the system recalibrates parameters before each print for consistently smooth and stable results.

Floating Damper Feet – Isolate unwanted vibration for better print quality
The H2D employs floating damper feet with a precisely tuned resonance frequency to effectively decouple the machine from desktop vibrations. This vibration isolation system ensures consistent print quality even in the presence of external vibration sources.

Dual-Nozzle Double Flexibility
Experience the artistry of mechanics and the full potential of multi-material printing with H2D’s groundbreaking dual-nozzle switching system. Lightweight, precise and reliable, it enables worry-free material changes, unlocking a world of creative possibilities.

Multi-Material Printing – Flexible and rigid, low-cost and other materials in one print
Combine flexible and rigid materials in a single print to create impressive interlocking structures and innovative designs beyond traditional manufacturing. Pairing high-performance materials with standard ones further reduces costs and boosts material efficiency by using premium materials only where necessary.

Dedicated Support Material – Perfect support with minimal waste, purging and reloading
Print with support is no longer a headache. With H2D’s dual-nozzle setup, one nozzle can be reserved for dedicated support material, allowing secured printing and a perfect support interface.

Efficient Multi-Color Printing – Fast and efficient multi-color printing
Dual-nozzle printing reduces purge cycles in multi-color prints. H2D’s smart algorithms optimize filament use, maximizing dual-nozzle efficiency to save time and materials.

Full-Auto Dual-Nozzle Offset Calibration – No manual tuning, no calibration tools
Experience hassle-free accuracy with eddy current sensing technology, delivering fast, contact-free, and fully automatic dual-nozzle offset calibration. Immune to nozzle debris, this system eliminates the need for manual tools or guides, streamlining your workflow.

Perception Drives Intelligence

The Bambu Lab H2Dredefines sensor supremacy in personal manufacturing. This technological orchestrator integrates a quad-camera computer vision system* with an array of 36 sensors, all harmonized through our proprietary neural algorithm – delivering micron-level measurement accuracy, self-optimizing calibration protocols, and real-time diagnostic intelligence.

Nozzle Camera – Monitor extrusion at the nozzle tip
The H2D features an AI-backed nozzle camera with a macro lens. This intelligent monitoring system continuously tracks extrusion patterns, immediately detecting material accumulation, filament deviations, and extrusion failures.

Pre-Flight Checklist by AI – Peace of mind, every time you print
Before each operational cycle, H2D’s vision system initiates a comprehensive pre-flight checklist: Chamber Integrity Scan – Detects debris across the entire print surface. Hardware Configuration Audit – Instantly identifies nozzle dimensions and build plate properties. Digital-Physical Alignment – Automatically verifies consistency between detected hardware specifications and active slicer parameters.

DynaSense Extruder – Intelligent sensing for precise extrusion control
Bambu Lab’s proprietary PMSM servo architecture establishes an intelligent extrusion governance system. It executes 20 kHz Torque/Resistance and position sampling to dynamically modulate electromagnetic torque vectors. Stabilizing extrusion and detecting filament grinding and clogging.

SOTA Filament Monitoring – 15 sensors on one filament path
Unlike legacy systems with single filament run-out detectors, the H2D features comprehensive material flow monitoring. Throughout the AMS-to-nozzle path, 15 strategic sensors form an intelligent network, continuously tracking five key parameters: feeding velocity, tension, filament tip location, extruder thermal environment, and dynamic extrusion pressure. This establishes an industry-leading filament behavior control system.

Health Management System 2.0 – Full support from start to finish
The HMS system uses sensors and cameras to pinpoint printing issues with advanced logic, similar to car diagnostics codes. It provides clear, detailed troubleshooting guidance, allowing you to quickly resolve problems and get back to your creative work.

Bigger, Faster, Better

The H2D delivers an expanded build volume, faster speeds, and enhanced capability to work with high-performance materials. It opens up new creative opportunities while broadening your material options, empowering you to take your projects to the next level.

King-Size Work Zone – Break free from size constraints
With a print volume up to 350mm×320mm×325mm*, creating large-scale projects has never been easier! From laser engraving on sizable objects to printing oversized models, the expanded capacity empowers you to bring even your most ambitious ideas to life.

350°C Hotend & 65°C Chamber Heating – Unleash the full potential of high-performance materials
Equipped with 65°C active chamber heating and a high-temperature hotend reaching up to 350°C, the H2D delivers precise closed-loop temperature control. This advanced system effectively eliminates warping and deformation in high-performance materials, ensuring superior layer bonding and maximizing their full potential.

REAL High-Flow Hotend* – Consistently print at 600mm/s
The H2D’s purpose-built high-flow hotend ensures reliable, high-speed printing at 600mm/s. Designed for consistent performance, it eliminates mid-print flowrate restrictions, enabling uninterrupted high-speed printing regardless of the print size or complexity.

Hardened Steel Extruder and Nozzle – Reliable for fiber-reinforced material printing
H2D’s extrusion system and nozzle are crafted from hardened steel, offering exceptional durability and wear resistance. Designed specifically for stable, long-term printing of high-performance fiber-reinforced materials.

Full-Metal Frame & Die-cast Chassis – Solid for high-speed & accuracy
The integrated die-cast aluminum alloy chassis offers a sturdy and stable structure, provides a rigid foundation for high-speed, large-format printing while minimizing accuracy loss due to micro-twisting.

Quick-Swap Nozzle – Nozzle change with 1-clip
Achieve truly tool-free, hassle-free hotend replacement with a simple lock clip – easy to operate, quick, and convenient without the need to unplug wires.

Safety, Checked!

H2D’s upgraded safety design enhances user confidence. Utilizing internal sensors, it provides sensitive active protection, preventing potential issues. The specialized air circulation and laser safety systems ensure optimal safety and a superior operating environment in all conditions.

Laser Protection
The Bambu Lab H2D Laser Edition comes standard with laser safety windows designed to enhance the safety of users observing laser operation. Additionally, doors are equipped with a sensor that triggers an emergency stop if opened during laser operation.

Emergency Stop & Loud Buzzer
The Bambu Lab H2D Laser Edition is equipped with an emergency stop and audible alarm, designed to help users quickly identify safety issues and easily pause the machine’s operation.

Flame-Retardant Chamber
The H2D features flame-retardant material through the chamber, designed to provide passive fire safety protection.

Flame Sensor
The Bambu Lab H2D chamber is equipped with flame sensors that are designed to quickly detect fire. In the event a fire is detected, the H2D unit can sound a buzzer and can be configured to send push notifications to help minimize potential risks.*

Auto Fire Extinguishing System*
An optional CO2 fire extinguisher system is available, which can be activated by the flame sensor in order to more quickly extinguish fire, adding extra peace of mind.

Multi-Sensor Closed-loop Temperature Control
The Bambu Lab H2D features a closed-loop temperature control system for all heating components, constantly adjusting temperatures based on real-time sensor data. This ensures stable and precise thermal management, keeping the device running efficiently and consistently within optimal temperature ranges.

Adaptive Airflow
Utilizing three mode-switch air flaps and chamber intake/exhaust, H2D’s Adaptive Airflow system delivers versatile air management for diverse operational needs. The system intelligently transitions between internal and external circulation, and provides selectable air filtration or heating, resolving challenges such as laser processing odors and dust, 3D printing fume filtration and chamber temperature control, offering a custom air quality solution for your personal manufacturing hub.

Seamless Cloud Connectivity & Off-The-Grid Isolation, For You to Choose

The H2D offers convenient cloud connectivity for remote control from any device. For security-sensitive applications, it also provides full offline functionality, ensuring physically isolated security. Users can control the printer, send files, and upgrade firmware without an internet connection. Additionally, Developer Mode enables MQTT port access for tinkerers who wish to integrate third-party components and software.*

AMS, Evolved.

The all-new 2nd-generation AMS systems, including the AMS 2 Pro and AMS HT, feature brushless servo feeding motors that significantly boost filament feeding efficiency, accelerating multi-color and multi-material printing. Even better, the 2nd-generation AMS introduces a filament drying function with active air vent on a fully sealed system, greatly enhancing drying efficiency and maintaining optimal filament conditions for extended periods.

Dry Filament Quickly and Intelligently – Electro-Magnetic Air Vent
Automated venting facilitates dehumidification during drying and airtight sealing for weeks of quality printing.

Auto-Rotate Drying
During the drying process, the filament spools rotate automatically to provide more even drying.

RFID Sync
AMS 2 Pro uses RFID to auto-match drying settings for Bambu official filaments, no manual input needed.

Speed Up! Faster Multi-Material Printing!
Powerful Bambu permanent magnet synchronous servo motor sped up the filament feeding by 60%

• Average 10 minutes saved per 100 filament changes
• Faster multi-color printing
• Evolved, Polished Design Details
• Tool-Free Filament Tubes Access
• Removing snapped filament from the first-gen AMS requires extracting all spools and disassembling the shell with two screws, taking 3-5 minutes. In contrast, the AMS 2 Pro offers direct, tool-free access to filament tubes from the top.

Why Do You Need an All-In-One Manufacturing Hub? Unlock new creative possibilities with hybrid processes. Space-saving all-in-one machine: Reclaim your workspace

One machine, the value of four

Notes

* 2 servo motors include the one on the AMS 2 Pro.
* The 3D mesh feature will be available shortly after the product release through a firmware update.
* Rotary Attachment is an optional equipment that will be available soon.
* Air Purifier is an optional piece of equipment.
* The BirdsEye camera is only equipped with the H2D laser edition, which can be added with the laser upgrade kit.
* Material CodeSync only works with Bambu official materials.
* The optional Vision Encoder is required for Motion Accuracy Enhancement.
* Auto Holes-contour Compensation must be enabled in Bambu Studio, and designated Bambu filament must be used.
* 350mm×320mm×325mm print volume is enabled by using identical filaments in both nozzles and printing with both nozzles.
* DynaSense Extruder filament grinding feature is limited by filament type.
* High-flow Hotends are optional equipment.
* The 600mm/s print speed refers to using Bambu PLA Matte filament.
* Auto Fire Extinguisher is an optional equipment, will be available soon after the product release.
* Due to safety protocol, Developer mode cannot be enabled when using Laser and Cutting functions.
* Push notifications require the use of Bambu Handy and cloud connectivity.
* Creator projects are provided for illustrative purposes only. Bambu Lab does not endorse, and disclaims any representations or warranties regarding creator projects, including, without limitation, the safety, marketability, or usability of any 3D printed works based on such projects. See our Terms of Service for more information.

* Big thanks to everyone who created these amazing projects. Automata by @Ross McSweeney; Hand Bag by @file4laser; 3D Printed Shoes – WhaleBerry @CloudBerry; Butterfly Lamp @Darts_3D; Bike Saddle @八宝; Bike Helmet @CloudBerry; Assassin Armor @寺工; Birthday Card @Viktor Losev; Automata by @Ross McSweeney; Birthday Card @popupcardKagisippo; MOCA Pro by @thrutheframe; AirPods Max Case by @设计发射塔; Tesla Model S Plaid by @Mr.Rod; 小米Su7 Ultra Prototype @大匠
