Fotric P7 High-performance Thermal Camera
Compatible with advanced software such as AnalyzIR® and NaviPdM®, revolutionising how inspections utilise thermal cameras.
Get the most out of your inspection work with the P-series thermal imager now!
Request a Quote
Prices shown are for the United Arab Emirates only and exclude VAT @ 5% Local Rate (Unless Otherwise Stated).
Other countries may incur additional import duties.
Please Contact Us for further details and pricing for your country or location.
Fotric P7 High-performance Thermal Camera
The P7 Industrial Thermal Camera offers up to 640*480 thermal resolutions, exceptional image quality, and precision for inspection work.
With an optional dual-view lens, you won’t need to carry or change lenses, saving time and space.
The P-series cameras boast top-class performance with <1°C image uniformity and <30mk sensitivity.
They also include on-device analysis power and a laser area measurement function.
These cameras are also compatible with advanced software such as AnalyzIR® and NaviPdM®, revolutionising how inspections utilise thermal cameras.
Get the most out of your inspection work with the P-series thermal imager now!
| Infrared Resolution |
640*480
|
| Detector Type | Uncooled infrared focal plane detector |
| Thermal Sensitivity（NETD) | 30mk(0.03°C) |
| Frame Rate | 30Hz |
| Optional Lens | Refer to the “Lens” Sheet in Catalog |
| Focus Mode | TurboFocus™ Speedy Intelligent Autofocus system for continuous, laser distance, graphic contrast, manual |
| Digital Zoom | 1-16x |
| Key Features | NaviPdM® (Optional) T-DEF® IREdge T-TWB® |
| Measuement Range | -20℃ ~ 120℃ (-4° F to 248° F)，0℃ ~ 700℃ (32° F to 1292° F)， 300℃ ~2000℃ (572° F to 3632° F) (Not applicable to dual-view or macro lenses) |
| Accuracy | ± 1℃ or ± 1 %, whichever is greater (ambient temp at 25℃, temperature range 0°C-100°C), ± 2℃ or ± 2 % for other temperature range |
| User-definable Measurement Tools (on device) |
25 spot markers 25 (rectangle or circle) 25 measurement lines |
| On-screen Analysis | Emissivity, Partially emissivity, Reflected temperature, Ambient temperature, Humidity, Distance, and IR window compensation. |
| Software |
AnalyzIR®, NaviPdM®
|
| Image Mode | Thermal\Digital\Picture-in-Picture\T-DEF® |
| Palettes | 16 standard palettes: Grey、Iron10、Iron、Rainbow、Grey10、GreyRed、MidGrey、Yellow、Rain、Rain10、Blue、GlowBow、Medical、Medical10、MidGreen、Prism. 16 inverted palettes |
| Highest/Lowest Temp Spot Mark | Yes,full-screen and measurement boxes both with highest/lowest temp spot marker |
| Digital Camera | 5-mega pixel and 13-mega pixel |
| Storage | SD card of 128GB memory, support expansion to 2TB |
| Scan Function | Support for QR code and Barcode |
| Annotation | Support Voice\Text\Bookmark\Favorate |
| Gallery | Image preview and analyze, video preview and analyze |
| Data Connectivity | WiFi Connection Bluetooth Connection USB Interface HDMI Interface FTP Data Transfer |
| Laser Measurement | Distance, Length, and Area |
| LED Light (torch and flash lamp) | Support |
| Battery Type | 3.6V，10000mAh lithium |
| Battery Life | 2 rechargeable batteries, over 4 hours per battery |
| Enclosure Rating | IP54 |
| Warranty | 2 years (standard), extended warranties are available,10 years for core detector |
| Supported Languages |
English, Spanish, German, Italian, Korean, Portuguese, Chinese Traditional
|
