Test Method
For the determination of the density, relative density, or API gravity of liquid petroleum products using portable digital density meters at test temperatures between 0 and 40°C (32 to 104°F). Its application is restricted to samples with a dry vapor pressure equivalent up to 80 kPa (11.6 psi) and a viscosity below 100 mm2 /s (cSt) at the test temperature.

Features

• Density measurement of crude oil, fuel oil and lubricant oil
• Oscillation method is specified in ASTM D7777
• Density or Brix measurement of various beverages such as milk, soft drink, fruit drink, etc.
• Measurement of alcohol or extract concentration of beer, whisky, wine, shochu(Japanese distilled alcohol), Japanese sake(fermented alcohol), etc.
• Measurement of Brix or constituent concentration of food materials for quality control purposes
• Density or SG measurement of oils and fats such as vegetable oil, animal fat and oil, etc.
• Conforming to Japanese Pharmacopoeia
• Concentration check of etching solution or acid pickling solution for electronic parts
• Concentration check of flux or plating solution

Specifications
Conforms to the specifications of: ASTM D7777
Measuring Method: Resonant Frequency Oscillation
Measuring Range: 0.0000 to 2.0000 g/cm3
Accuracy: ± 0.001 g/cm3
Temperature Range: 0 to 40.0 °C
Temperature Resolution: 0.1 °C
Data Storage: Up to 1,100 samples
Power Supply: Alkaline battery LR03 (AAA) 1.5V 2pcs
Battery Life: Approx. 90 hours
Weight: Approx. 360 g (0.794 lbs)

Additional Accessories
K86310-1 Calibration Fluid Water 0.99821 g/cm3 10mL pk/2
K86310-2 Calibration Fluid Dichlorotoluene/Water 1.249 g/cm3 10 mL
