Mitutoyo 293-669-20 Digital Absolute Micrometer QuickMike

Mitutoyo 293-669-20 Digital Absolute Micrometer QuickMike

75-105mm

AVAILABLE IN STOCK

Prices Start From Call for price

Prices shown are for the United Arab Emirates only and are excluding VAT @ 5% Local Rate (Unless Otherwise Stated).

Other countries may incur additional import duties – Please Contact Us for further details and pricing for your location.

Description
Specifications
Request A Quote

Description

This Quickmike, with a non-rotating spindle, delivers much faster movement than standard models.
The ABSOLUTE Digimatic Micrometer Quickmike offers the following benefits:

  • With 10 mm feed per revolution, it delivers twenty times as fast as standard devices.
  • Excellent resistance against water and dust (IP65) enables this micrometer to be used in machining situations that include splashing coolant fluid.
  • ABSOLUTE linear scale means no restriction on adjustment speed.
  • Larger measuring range – 30 mm compared with 25 mm – than standard micrometer.

Digital/Analog:
Digital
Inch-Metric:
Metric
Range:
75 – 105 mm
Digital step:
0.001 mm
Maximum Permissible Error J MPE:
±3 µm
Accuracy:
±3 µm
Flatness:
0.3 µm
Parallelism:
3 µm
Data output:
Yes
Display:
LCD, character height 10 mm
Measuring spindle:
ø6.35 mm, non-rotating, spindle feed 10 mm
Measuring force:
5 – 12 N
Power supply:
1 battery SR-44
Battery life:
Approx. 5 years
Delivered:
including Box, gauge block (from 25 mm upward), 1 battery
ABS / INC (INC ZERO):
Yes
Function lock:
Yes
HOLD:
Yes
Mass:
585 g
