FJD Trion GC100 H36 PRO
An advanced 3D motor grader automatic control system developed by FJD Trion. It utilizes satellite GNSS positioning, multi-sensor integration, and real-time 3D design models to automate blade adjustments, delivering centimeter-grade grading accuracy in a single pass.
Request a Quote
Prices shown are for the United Arab Emirates only and exclude VAT @ 5% Local Rate (Unless Otherwise Stated).
Other countries may incur additional import duties.
Please Contact Us for further details and pricing for your country or location.
FJD Trion GC100 H36 PRO
An advanced 3D motor grader automatic control system developed by FJD Trion. It utilizes satellite GNSS positioning, multi-sensor integration, and real-time 3D design models to automate blade adjustments, delivering centimeter-grade grading accuracy in a single pass.
Automated Blade Control: Automatically controls the grader blade based on the loaded 3D design model and live terrain feedback.
Operation Modes: Supports design data imports, depth/slope elevation modeling, and extended slope applications without requiring traditional physical measuring and staking.
Efficiency Boost: Accelerates site leveling, road construction, and large-scale earthworks, raising overall project progress speeds by up to 30%.
TPS Version Available: Also offered in a Total Positioning System (TPS) configuration for specialized high-precision job sites.
| Terminal | |
| Dimensions | 284 × 189 × 22.5 mm |
| Display | 10.1″，1920 × 1200，750 cd/m² |
| Performance | Processor: Octa-core, 2.2 GHz |
| Memory: 8 GB RAM，128 GB ROM | |
| Power Supply | DC 7–30 V |
| Wireless Communication | Wi-Fi: 802.11 b/g/n (2.4 GHz) |
| Bluetooth: 5.0 (BLE) | |
| Battery | Built-in lithium battery, 10000 mAh / 3.8 V (non-removable) |
| Environmental Conditions | Operating temperature: -20 °C to +60 °C |
| Storage temperature: -30 °C to +70 °C | |
| Ingress Protection | IP68 waterproof and dustproof |
| Control Box | |
| Dimensions | 200 × 155 × 63 mm |
| Communication | Wi-Fi/BT/Ethernet |
| Power Supply | DC 9–36 V |
| Environmental Conditions | Operating temperature: -40 °C to +60 °C |
| Storage temperature: -40 °C to +85 °C | |
| Ingress Protection | IP67 waterproof and dustproof |
| Radio Antenna | |
| Frequency Range | 410–470 MHz or 902–928 MHz |
| Gain | 2 ± 0.5 dBi |
| Cable Length | 4.5 m |
| GNSS Antenna | |
| Passive Antenna Characteristics | Frequency Range: Multi-constellation, full-band GNSS; Gain: ≥ 5.5 dBi |
| Polarization: RHCP (Right-Hand Circular Polarization) | |
| Horizontal Coverage: 360°; Output Impedance: 50 Ω; VSWR: ≤ 2.0 | |
| Environmental & Mechanical Characteristics | Operating Temperature: -45 °C to +85 °C |
| Storage Temperature: -55 °C to +85 °C | |
| Humidity: Up to 95% (non-condensing) | |
| IMU | |
| Resolution | <0.01° |
| Operating Voltage | DC 9-36V |
| Output Frequency | Up to 100 Hz |
| Operating Temperature | -40°C to +85°C |
| Ingress Protection | IP67 waterproof and dustproof |
